16 Feet HVLS Fan Manufacturer
| Brand | : | Austar Fan India |
|---|---|---|
| Product | : | HVLS Fan |
| Type | : | Geared |
| Size | : | 16 Feet |
| Blades | : | 5 Aero Blade |
| Speed | : | 10 rpm Maximum ( Variable from 0 to 50 ) |
| Color | : | Matt black, Customizable |
AUSTAR AS series Fan are Geared Type HVLS Fans driven by German make Geared Motors, with five Aero Blades and Single piece die casted Hub. Are controlled through Variable Frequency Drive for Reverse / Forward and speed adjustment features. Complies to international safety standards. Available in Standard Matt Black color and customized color options.
| Parameter | Specification | ||
| 1. | Make | “AUSTAR“ | |
| 2. | Model No. | AS125 | |
| 3. | Fan Size | 16ft Dia | |
| 4. | No. of Blades | 5 No.s | |
| 5. | Air Volume | 135000 CFM | |
| 6. | Motor Rating | 0.75 KW | |
| 7. | Speed | 10 rpm Maximum ( Variable from 0 to 50 ) | |
| 8. | Noise | 60 – 65 db | |
| 9. | Input Power | Single Phase / Three Phase – 50Hz | |
| 10. | Weight | 110 Kgs | |
| 11. | Construction | Frame Structure | M.S. ( Powder Coated ) |
| Hanging Structure | M.S. ( Powder Coated ) | ||
| Impeller ( Hub ) | Single Piece Aluminum Die Casted | ||
| Fasteners | High Tensile 10.9 Grade HEX Bolts (Unbrako / TVS make) | ||
| 12. | Blades | Design | Cambered Aerofoil Design |
| M.O.C. | Aluminum 6063 ( Powder Coated ) | ||
| Sectional Width | 220mm | ||
| Wall Thickness | 2mm | ||
| No. of Ribs | 2 Ribs | ||
| 13. | Electric Geared Motor | Make | NORD ( German Make ) |
| Insulation Class | Class F | ||
| Efficiency Class | IE2 | ||
| Enclosure | IP55 | ||
| 14. | Control Penal | Mounting | Wall Mounting 4 – 5 ft from Floor Level |
| VFD Make | ‘Danfoss/Fuji’ Make | ||
| Enclosure | IP 55, Power Coated Steel cabinet | ||
| Compatibility | BMS Compatibility | ||
| 15. | Safety | Certification | Compliance certificate to CE requirements |
| Bolted Joints | All Nuts are self locking type Nylock Nuts which
eliminates chances of loosening.
As additional Safety All Bolted joints are wrapped with SS wire Rope. |
||
| Motor – Hub Assembly | It is coupled through self locking type Split
Couplings.
As an additional safety Antifall S Bends are provided to prevent dropping of Hub in event of coupling failure. |
||
| 16. | Warranty | 3 Years f or Hub, Blade, &
Structure.
1 Year for Geared Motor & Controller. |
|
Key Component Specifications
Gear
Moter
German Make
Nord / SEW German make. IP 55 Protection, IE2 Efficiency, with Reinforced Bearing.
Blade
Mounting
Hub
German Make
Aluminium HE9 Grade. Die Casted Single Piece with Radiography tested.
Blades
German Make
Aluminium HE9 Grade. Having broadest blade section in market. Having Two Ribs for extra strength.
Paint
Hot Deep Galvanized
Driven by VFD of reputed make
i.e Lenze /
Danfoss
/
Crompton.
Control : Operated through KeyPad having easy and long life keys for Start / Stop, Reverse / Forward and Speed increase / decrease. Cable connection are through plug and play type for easy installation, maintenance and trouble free long lasting operation.
Models are CE certified by third party agency ‘TUV Nord’
